model | Specs |
---|---|
body color | black |
Material | Steel, tempered glass |
Motherboard support | E-ATX / ATX / M-ATX / Mini-ITX |
Optical drive support | N / A |
Hard disk | Hard disk shelf: 3.5 inches * 2 , 2.5 inches * 1 ( shared with 3.5 inches) Back: 2.5 inches * 2, 3.5 inches * 1 (shared with 2.5 inches) |
PCI card slot | 7 |
Front interface | USB 3.0 Type-A × 1, USB 2.0 Type-A × 2, HD audio interface |
Fan support | Front: 3 * 120mm, 3 * 140mm Top: 2 * 120mm, 2 * 140mm Rear: 1 * 120mm (chassis without fan and fan screws) |
Water cooling support | Front: 360mm Top: 240mm Tail: 120mm |
CPU heat sink height limit | 165mm |
Graphics card length | 350mm |
Power limit | 200mm (without fan or water cooling on the front panel, the power limit is 230mm) |
Product size (L * W * H, mm) | 458 × 215 × 482 |
Net weight (kg) | 7.1kg |
