| Model Name | M32A5F | ||
| LCD Panel |
|
31.5" Diagonal White LED-Backlight | |
| Brightness(Typical) | 250cd/m2 (Typical) | ||
| NTSC | NTSC 85% | ||
| Contrast(Typical) | 3000:1 (TYPICAL) | ||
| Resolution (H x V) | 1920*1080 | ||
| Aspect Ratio | 16:09 | ||
| Response Time(Typical) | GTG 8ms | ||
| View Angles LR,UD(CR>10) | 178(H)/178(V) (CR>10) | ||
| Panel Surface | Anti-Glare type,Haze 25% | ||
| Display Colors | 16.7M colors | ||
| PC Input Range | Horizontal Freq. | 54.15 to 84.38KHz | |
| Vertical Freq. | 49 to 75Hz | ||
| Max. display frequency (Resolution H*V/Fv) |
1920(H) ×1080(V)@60Hz | ||
| Interface | Input 1 | VGA | |
| Input 2 | DVI | ||
| Input 3 | HDMI | ||
| Power | Consumption(Typical) | On：< 48 W (Typ.) Standby <= 0.5 W Off <= 0.5 W |
|
| Power Range | AC 100-240V 50/60Hz | ||
| Power Mode Indicator Light |
Power on : Blue (LED) Power saving : Blue Flicker (LED) |
||
| Operating Condition |
Temperature | 0℃ ～ 40℃ | |
| Humidity | 20% ~ 85%, non-condensing | ||
| Physical | Dimension (W*D*H) |
710.38 *509.55 *212.5mm | |
| Packing Dimension (W*D*H) |
813x157x540mm | ||
| Net Weight | 6.3kg | ||
| Gross Weight | 8.47kg | ||
| Tilt | -5∘~ 15∘ | ||
| Kensington Lock | Yes | ||
| VESA Mounting | 100*100 | ||
| Controls | Front Control | Menu,Down,Up,Exit, POWER | |
| On Screen Display | 2015 | ||
| Color | Warm, Nature, Cool, User Mode | ||
| Preset Mode | PC, Movie, Game, ECO Mode | ||
| Accessory | Power Cable | Yes (1.5M) | |
| Adapter | AC 100-240V 50/60Hz | ||
| HDMI-HDMI Cable | Yes (1.5M) |
