| Model | RS-850-AFBA-G1 |
| Type | Intel Form Factor ATX 12V V2.31 |
| Dimension (W x L x H) | 150 x 170 x 86mm / 5.9 x 6.7 x 3.4 inch |
| Input Voltage | 90-264Vac (Auto Range) |
| Input Current | 10 - 5A |
| Input Frequency Range | 60 - 50Hz |
| PFC | Active PFC (>0.9) |
| Power Good Signal | 100-500ms |
| Hold Up Time | >17ms |
| Efficiency | 90% Typically |
| MTBF | >100,000 Hours |
| Protection | OVP/UVP/OPP/OTP/SCP |
| Output Capacity | 850W |
| Operation Temperature | 0~40°C |
| Regulatory | CE/TUV/TUV-SUDNRTL/FCC/GOST/CCC/BSMI/C-tick/KCC |
| Fan | Silent FDB 135mm |
| Certifications | 80 Plus Gold |
| Connector | M/B 20+4 Pin Connector x 1 CPU 4+4 Pin x 2 PCI-e 6+2 Pin x 6 SATA x 9 4 Pin Peripheral x 4 4 Pin Floppy x 1 |
